Automatic For Rigid 1.2m PCB Placement Machine

Name: China Automatic For Rigid 1.2m PCB Placement Machine Manufacturers Suppliers Factory - Good Price - Eton Automation
Brand: Eton
SKU: 207604857

Apply to the 0.6m, 0.9m, 1.2m rigid PCB and 0.5m, 1m LED flexible strip, producing with 4 types materials at the same time with high capacity, available for board with any proportion of LED chip and resistor. Dual arm four module, 17 nozzles for each mounting part, part A/B/C/D can be mounted separately or synchronously. Calibration automatically, high precision, available for RGB. Exclusive patent technology: Group to take and group to mount. IPC9850 capacity: 200000-250000 CPH

Send Inquiry

Features

Automatic for rigid 1.2m PCB placement machine

Production description

Apply to the 0.6m, 0.9m, 1.2m rigid PCB and 0.5m, 1m LED flexible strip, producing with 4 types materials at the same time with 250000 CPH capacity, available for board with any proportion of LED chip and resistor.

Owing an exclusive technology of group picking and group placing, PCB size is 1200*330 can mount LED 3014/3020/3528/5050 or resistor, capacitor and bridge rectifiers, etc.

Machine parameter

Model	HT-F9
PCB length width	Max: 1200330mm Min: 100100mm
PCB thickness	0.5-5mm
PCB clamping	Adjustable pressure pneumatic
Mounting mode	Group picking and group placing
Mounting precision	±0.02mm

Machine application

product-700-500

Our advantage

ETON is the pioneer of SMT machine field in China which have more than 11 years experiences. And owned CCC, SIRA, CE certificates with 9 invention patents, 112 practical patents, 12 software copyrights of intellectual property technologies.

Oversea market:The products exported to more than 30 countries and regions, including South Korea, India, Vietnam, Tunisia, Egypt,Turkey, Russia, Brazil etc.

product-700-500

Our Exhibitions

As an experienced company of trading SMT pick and place machine with more than 30 countries and regions aboard, Eton has participated in many exhibitions of foreign countries, such as India Mumbai Exhibition, India Delhi Exhibition, Egypt Exhibition, Turkey Exhibition, Pakistan Exhibition, etc. And also we have took part in our domestic exhibition, like Guangzhou Guangya Exhibition, Shanghai Munich Exhibition, Chongqing LED light Exhibition, etc.
