The Loading Machine Is Controlled By PLC

The loading machine is controlled by PLC

SMT production line circuit board loading device

PLC control, color man-machine interface operation

Special cylinder pushing plate structure is adopted, and the force and speed of pushing plate can be adjusted

Auxiliary positioning brake system, accurate positioning, fast lifting speed and high production efficiency

Multiple electrical distribution circuit circuit protection, safe and reliable

Audible and visual alarm system, abnormal information text prompt, easy operation and maintenance

Standard SMEMA signal communication mode

Loading machine, also known as plate machine, brick stacking machine, plate stacking machine, plate lifting machine and stacking machine.

Yuanchuang automatic loading machine adopts mechanical design, which is easy to operate and maintain without operation and computer automatic control.

Technical parameter

Work flow of loading machine

A support plate is usually used for more than ten seconds during block production. Now, the commonly used method is to manually put the support plate into the plate bin of the plate feeder, and then the plate feeder intermittently sends the support plate to the block machine. Since the weight of each supporting plate of large and medium-sized block machine has reached several tens of kilograms, the manual loading is very labor intensive, and the automatic loading machine is a special equipment to replace the manual loading.

Composition of loading machine

The automatic plate loading machine is composed of frame, plate lifting system, plate pushing system, deviation adjusting system, idler, positioning frame and control system.

Features of loading machine

The advantages of the full-automatic plate feeding machine are that it does not need special equipment foundation and can be used with the plate feeding machine when placed on the hardened ground, which reduces the labor intensity of the operators, improves the work efficiency, saves labor and reduces the production cost; The whole machine has no moving cables and electrical components, which ensures the personal safety of operators; The whole equipment has the characteristics of simple and reasonable structure, flexible operation and use, reliable performance and wide application range.

If you want to know the price, please contact me on wechat \ WhatsApp + 8613823702034
