T9-2S LED STRIP Smt Making Machine

HIGH SPEED AND PROFESSIONAL PICK AND PLACE MACHINE T9-2S LED STRIP making machine



Technical parameter

HIGH SPEED AND PROFEESIONAL PICK AND PLACE MACHINE T9-2S
PCB size	250(±10)mm* any length
PCB thickness	0.1-0.5mm
PCB clamping	Vacuum adsorption, cylinder clamping, track width adjustable
Mounting way	Group picking and group placing
Mounting mode	Double-rail+four groups of placement heads
No. Of camera	10 sets of digital camera
Repeat precision	±0.05mm
Mounting height	≦5mm
Mounting speed	Double side: 500000 CPH, Single side: 250000 CPH
Components	LED 3014/ 3020/ 3528/ 5050 and resistor, capacitor, bridge rectifiers etc.
power	350 AC 50Hz
Power consumption	9.6KW
Electrical control	Independent research and development by ETON
Motion control card module 2 set
Feeding way	Intelligent electric feeder with double motor
No. Of feeder station	Double side 136 PCS, Single side 68 PCS
No. Of head	Double side 136 PCS, Single side 68 PCS





Market

Our products had exported to more than 30countries and regions, including South Korea, India, Vietnam, Tunisia, Egypt,Turkey, Russia, Brazil etc. And here are some of our big customers:

SURYA, POLYCAB, FIEM, RK, GK, TECHNO LED, CALCOM, ACK , KENDAL, RangDong, UNISTAR, and so on.



Package and delivery

All machines are packed with vacuum and wooden packing like the one in the pictures.

Step 1. Film packaging

Prevent the machine from dust ,water,crash and shaking.

Step 2. Add foam+film packaging

Double safe protection,Prevent the machine from crash and shaking.

Step 3. Unique tin foil packaging

Add tin foil packing can prevent the film from scratch broken.

Step 4. customized Strong wood carton packing

The customized strong wood packing for ocean ship,The machines are fix oi in the wood carton, effectively prevent collision and shock.



FAQ

Why do you choose us?

We are the leading manufacturer of global optoelectronic high-speed pick and place machine, the products are exported to more than 20 countries and regions, including South Korea, India, Vietnam, Tunisia, Egypt, Turkey, Russia, Brazil,etc.



How about the operation of machine?

It is easy to operate of the machine. It takes about three to five days to get familiar with the operation.



How to make payment?

T/T.



what is your payment terms?

30% deposit in advance and 70% balance before shipment.



What machine can I buy from you?
We will also produce patch peripheral equipment, mainly the following several: Multi-function placement machine, high-speed placement machine, dispensing machine, loading machine, printing machine, reflow soldering, etc.
