Pick Twice And Once Place 144 PCS Heads Placement Machine
video
Pick Twice And Once Place 144 PCS Heads Placement Machine

Pick Twice And Once Place 144 PCS Heads Placement Machine

Pick twice and once place 144 PCS heads Placement machine Machine main features The range of feeder station is double of placement four kinds of materials at the same time. Automatic production with identification date, correction and fill missing component automatically. Flight recognition...

Send Inquiry

Features

Pick twice and once place 144 PCS heads Placement machine



Machine main features

The range of feeder station is double of placement four kinds of materials at the same time.

Automatic production with identification date, correction and fill missing component automatically.

Flight recognition camera, no pause to detect the presence or absence of components, component adsorption state, prevent placement errors.

The clamping rod is driven by the air cylinder to correct the materials taken by mounting head.

With the function of filling missing component automatically, realize industry 4.0 Unmanned Workshop.

Complaint with CE standards.



PCB size

250(±10)mm* Any length

PCB clamping

Vacuum adsorption, cylinder clamping, track width adjustable

Mounting way

Group picking and group placing

Repeat precision

±0.05 mm

Mounting height

≦5 mm

Mounting speed

Double side: 500,000 CPH

Single side: 250,000 CPH (Optimum speed)

No. of feeder station

Double side: 136 PCS (Single side: 68 PCS)

No. of nozzles

Double side: 136 PCS (Single side: 68 PCS)



product-700-500

SMT Line solution

product-700-500

Certificates

As an experienced manufacturer in SMT machine, we obtained a number of intellectual property technologies, including 9 invention patents, 112 practical patents, 12 software copyrights, with our won R&D department for production and inspection. And also earned the oversea certificates as CE, CCC, SIRA,

etc.

product-700-500

Market

Our products had exported to more than 30 countries and regions, including South Korea, India, Vietnam, Tunisia, Egypt,Turkey, Russia, Brazil etc. And here are some of our big customers:

SURYA, POLYCAB, FIEM, RK, GK, TECHNO LED, CALCOM, ACK , KENDAL, RangDong, UNISTAR, and so on.

product-578-672

Packages

Our package step is follow the blowing:

STEP 1: Film packaging to prevent the dust and water;

STEP 2: Packing in a foam cotton stretch a film to protect the outside of the machine;

STEP 3: Vacuum paper package and moisture proof bag, to keep dry during the transportation;

STEP 4: Equip with sturdy wooden boxes to ensure the safety of the machine, then transportation by trucks to the specified port.

Delivery: by sea, air, land transport.

product-700-500
