CIRCUIT BOARD MAKING MACHINE
1. Greatly upgrade the "high-speed universal integrated mounting head", which has high productivity and versatility 2. There is no need to replace the mounting head, and it supports 0201-10mm packaging materials and IC materials 3.40 suction nozzles, each controlled by an independent servo motor 4. Double headed, double track, the maximum PCB size is 500*450mm 5. The company can achieve 120000cph under the optimal conditions
Features
CIRCUIT BOARD MAKING MACHINE
PARAMETER
线路板/PCB | |
PCB板尺寸/PCB size(L* W) | 最大尺寸Max size:单板500mm*450mm(single PCB) 双板500mm*300mm(double PCB) 最小尺寸Min size: 50mm*50mm |
PCB板厚度/PCB thickness | 0.5-4.5mm |
PCB板固定方法/PCB clamping | 气缶I夹板、轨道宽度可调/Cylinder clamping, track width adjustable |
定轨方式/Rail | 双轨双臂(1 轨4轨为固定轨道)/2 Rail,2 gantries(Rail 1,4 are fixed rail) |
系统/Sy stem | Windows 7 |
软件/Software | 自主研发/ R&D independently |
生产管理MES系统/Production management MES system | 提供要求定制(选配项)/ Customized(Option) |
离线编程/Off-line programming | 有/Available |
相机数M/No. of camera | 4套/4 sets (数字相机 Digital camera ) |
固定飞拍识别元器件/Bottom vision camera recognition | |
视觉对位+MARK校正/Vision alignment+Mark correction | |
重复精度/Repeat precision | + 0.02mm |
贴片高度/Mounting height | W6mm |
贴片速度/Mounting speed | 120000CPH (本公司最优条件下)(Optimum speed) |
贴装零件范围/Components range | 0201~10mm 封装料及 IC 料/Min 0201 packagesand IC etc. |
使用电源及功率/Power | 380AC 50HZ 6KW |
使用环境/Operating environment | 23°C±3°C |
传输方向/Transmission direction | 标准(单向)/Standard: Single direction |
传送方式/Transmission mode | 在线/Online drive |
定位方式/Position mode | 光学/Optical |
耗气量/Air consumption | 0.4-0.6mpa ( 4-6kgf/cm2) 1 50N/min |
电气控制/Electrical control | ETON 自主研^/Independent research and development by ETON |
运动控制卡模块 1 套/Motion control card module 1 set | ETON 自主研发/Independent research and development by ETON |
XYZ轴驱动方式/X,Y,Z Axis drive way | 高端磁悬浮电机+伺服电机/High-end magnetic linear motor +Servo motor |
可放置送料器数S/No. of Feeder station | 双边送料器台车站位32PCS,可装物料64盘(单边送料器台车站位16PCS, 可装物料32盘) Double side docking cart slot 32PCS,tape reel packages:64PCS(single side docking cart slot 16PCS,tape reel packages:32PCS) |
吸嘴安装数＞/No. of Heads | 双边40PCS(单边20PCS)/Double side:40pcs(single side:20pcs) |
送料方式/Feeding way | 双头智能送料器/Intelligent Double head Feeder |
Machine indroduction
1..40 suction nozzles, each controlled by an independent servo motor
2.Double headed, double track, the maximum PCB size is 500*450mm
3.The company can achieve 120000cph under the optimal conditions
Our service
Before you buy our machine, we will give you the plan of the whole SMT production line. As long as it is about SMT related knowledge, we will try our best to answer for you.In addition, we also provide free door-to-door installation service, free replacement of all parts damaged during the warranty period, free online video teaching for 7 days and 24 hours, and free software update for life
Exhibition
We attend many exhibitions every year.
Not only in China, India Delhi, Indian Mumbai, Pakistan Karachi, Turkey Istanbul, Egypt Cairo, Russia Moscow, Vietnam Hanoi etc.
We occurred 85% percent in China LED lighting markets, but also send machines to India, Korea, UK, Russia, Egypt, Turkey, Vietnam, Japan, Australia, Poland, etc more than 20 countries
FAQ
Q: How is the training?
A: After purchasing our products, you can send your engineers to study in our factory, or we can send our engineers to yourfactory to train your staff for you .
Q: Do you have a product certification certificate?
A: Our products have CCC, CE, SRIA certification.
Q: How about the after-sale service? How about the warranty?
A: We have a team of professional engineers to solve your problems. Any parts that require repair and replacement are free ofcharge during the warranty period. We can also provide you with training and on-site installation, and support remote control of the machine, the machine uses Chinese and English interface, very easy to operate.
